KEXINT Fiber Optic Patch Cord Cable 1ft LC Male To SC Female Multimode 50/125 2.0mm Duplex

Product Categories
SHENZHEN KXIND COMMUNICATIONS CO.,LTD
Contact Now

KEXINT Fiber Optic Patch Cord Cable 1ft LC Male To SC Female Multimode 50/125 2.0mm Duplex

Brand Name : KEXINT

Model Number : LC(M)-SC(F) 0.3m OM2 Duplex

Certification : CE/ROHS/ISO9001

Place of Origin : CHINA

MOQ : 100+PCS

Price : dollars+0.86+pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000+peace+week

Delivery Time : 8 days

Packaging Details : box

Fiber Type : OM2

Color : Orange

Connector Type : LC(Male)-SC(Female)

Length : 0.3m

Jacket Material : LSZH

Cable Diameter : 2.0 Mm

Package : Carton Box

Operating Temperature (°C) : -40℃~85℃

Contact Now

Fiber optic patch cord means that both ends of the optical cable are equipped with connector plugs to realize the active connection of the optical path; one end with a plug is called a pigtail. Fiber optic patch cords are similar to coaxial cables, but without the mesh shield. In the center is the glass core for light propagation. In a multimode fiber, the diameter of the core is 50 μm to 65 μm, roughly equivalent to the thickness of a human hair. The single-mode fiber core has a diameter of 9 μm. The core is surrounded by a glass jacket with a lower refractive index than the core to keep the fiber inside the core. On the outside is a thin plastic jacket to protect the envelope.
Features:

· Low insertion loss and high return loss

· The patch cord can be customized according to customer’s specific requirements

· Strict quality testing: IL and RL 100% test.

· All materials meet the RoHS standard.

Characteristics:

1) Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
2) Ferrule End-face: PC, UPCAPC
3) Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
4) Cable Quantity: Simplex, Duplex, 6cores ,12corns, 16cores, 24cores, 36cores, 48cores...
5) Cable Diameter: φ3.0mm,φ2.0mm, φ0.9mm
6) Cable Length: 1, 2, 3 meter or customized
7) Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum ,Armored
Applications:

· Optical fiber communication system

· telecommunication network

· LANs and WANs

· CATV

· FTTX
Our advantages:

1.Good reply: Your inquiry related to our products or price will be replied within 24 hours.

2.OEM&ODM: We can help you to design or put your logo and company name into products.

3.Remote Technical support&Full Technical Document

4.Warranty: 1 year warranty( While the warranty is not responsible for those broken by violence or updated with other brands.)

5.English software, English Indicator

6.Professional, Very competitive price

7.Large Stock, Fast Delivery

8.Quality Assurance
KEXINT Fiber Optic Patch Cord Cable 1ft LC Male To SC Female Multimode 50/125 2.0mm Duplex
item
value
Model Number
LC(M)-SC(F) 0.3m OM2 Duplex
Type
Fiber optic patch cord
Place of Origin
China
Brand Name
KEXINT
Use
FTTX
Warranty Time
5 years
Network
None
Fiber Type
OM2
Color
Orange
Connector Type
LC(Male)-SC(Female)
Length
0.3m
Jacket Material
LSZH
Cable Diameter
2.0 Mm
Package
Carton Box
Factory
yes
Operating Temperature (°C)
-40℃~85℃
Certification
CE/ROHS/ISO9001
